Tire Steel Wire Separator

The sidewalls cut by the tire ring cutter contain a large number of steel wires. the use of a tire steel wire separator can efficiently achieve the separation of rubber and steel bead, respectively, the recovery of rubber and steel wire, and improve the utilization rate of materials.

  • Capacity: 120pcs/h
  • Motor Power: 18.5KW
  • Application: Separate steel wire and rubber from tire sidewalls
  • Service: Warranty, installation, technical support, etc.
  • Widely applicable to all kinds of tires
  • Improve material utilization and increase additional revenue
  • Meet environmental requirements
Contact Us
tire steel wire separator

Key Features of the Tire Steel Wire Separator

  • Key parts are made of alloy steel to prolong service life
  • Stable operation and energy saving to meet environmental standards.
  • Efficient separation of rubber and steel wires to improve the recycling rate of used tires
  • Small footprint for easy integration into tire recycling lines
tire steel wire separator
Play

Parameters of Tire Steel Wire Separator

ModelSWS-100 steel wire separator
Capacity120pcs/h
Motor Power18.5KW
Machine Weight1800kg
Machine Size2*1.9*1.8m

How Does the Tire Wire Removal Machine Work?

The tire steel wire separator mainly includes: frame, two relatively rotating rollers, a motor and transmission system, a control system, inlet and outlet. It works as the following steps:

  • Put the tire sidewall cut by the tire ring cutter between the two rollers.
  • The two rollers rotate relative to each other at the same speed, and the rim is clamped into them for strong extrusion.
  • The tire sidewall is squeezed, sheared, and torn between the rollers.
  • Under the repeated rotation of the rollers, the gel is completely separated from the rim.
  • Ultimately, the steel rim and rubber are completely separated, and the steel wire is discharged separately, which is convenient for subsequent processing or recycling.
